DirecTV makes several satellite receiver models, some of which are capable of transmitting two different signals to separate television sets. Getting each signal to a TV requires a coaxial splitter available at electronics stores, plus a length of coaxial cable with couplers on the ends for connecting to each TV. The cables attach to the signal splitter in a few minutes.
Step 1
Connect a coaxial cable to the Out to TV jack on the back of the DirecTV receiver. The cable attaches by turning the coupler on the end clockwise around the threaded jack. Be careful to insert the meal pin inside the cable into the hole in the jack without bending or breaking the pin.
Video of the Day
Step 2
Connect the other end of the cable to the Coax IN jack on the signal splitter. This is usually the only jack on one side of the splitter. The output jacks are on the other end.
Step 3
Attach coaxial cables to the OUT to TV jacks on the signal splitter, tightening the couplers by hand.
Step 4
Route a cable to the back of each TV and secure the coupler to the RF IN or Coax IN jack on the back of each set.
Step 5
Plug the receiver and both TV sets into electrical outlets.
